Technician Menu Page 24/33
Programming instructions SYCLOPE ODISEA
®
Adjust the scale of the
analogue output.
► Follow this same process to adjust the other analogue outputs.
8) Programming the alarm thresholds
Allows you to define the alarm thresholds (top and bottom) of the various measurement parameters.
Adjust the alarm thresholds
► Follow this same process to adjust the other alarm thresholds.
Specialist level
Technician code
System date
Setting(s)
Calibrations
General timers
Analogue outputs
Analogue outputs
pH
Chlorine
Analog. Output IA1
pH
Basse…(4 mA) : 06.50
Haute…(20 mA) : 8.50
Technician level
Langue/Language/…
Set the time
Displays
Histories
Specialist level
Technician code
System date
Setting(s)
Calibrations
General timers
Analogue outputs
Technician code
System date
Setting(s)
Calibrations
General timers
Analogue outputs
Alarms
Alarm thresholds
Temperature
pH
Chlorine
Alarm thresholds
Min.….…(pH): 6.80
Max.……(pH): 7.90
