SYCLOPE ODISEA - Table of Events and Alarms Histories

Table of events and alarms histories Page 31/33
Programming instructions SYCLOPE ODISEA
®
VI. Table of events and alarms histories
Table of events :
n° Message displayed Meaning
00 Service on Starting controls (Start key)
01 Service off Stop controls (Stop key)
02 Stop from ext. entry External break for controls
03 Stop from flow switch Flow switch break for controls (No water circulation)
04 Temperature Calibration Calibration of the temperature sensor
05 Calibration pH Calibration of the pH sensor
06 Redox (ORP) calibration Calibration of the Redox (ORP) sensor
07 Chlorine calibration Calibration of the Chlorine sensor
08 Bromine calibration Calibration of the Bromine sensor
09 Flow switch calibration Calibration of the flow switch sensor
10 Powering Powering of the controller
Table of alarms :
n° Message displayed Meaning
00 Temperature default Measuring in error or sensor missing
01 pH sensor default Measuring in error or sensor missing
02 ORP sensor default Measuring in error or sensor missing
03 Chlorine sensor default Measuring in error or sensor missing
04 Bromine sensor default Measuring in error or sensor missing
05 Alarm threshold Temperature Abroad thresholds set
06 Alarm threshold pH Abroad thresholds set
07 Alarm threshold Redox (ORP) Abroad thresholds set
08 Alarm threshold Chlorine Abroad thresholds set
09 Alarm threshold Bromine Abroad thresholds set
