12
GO User Guide
Travel mode - System diagram
Travel mode is the fully compacted position of your GO.
• Total capacity of the GO is 1650 lbs.
• Max. carrying capacity of the deck is 810 lbs.
• Rack capacity is 165 lbs. GO total max. load capacity is 810 lbs.
Before moving, it is very important to be sure:
• Stabilizer jacks are retracted underneath deck
• Swivel jack is rotated into horizontal position
• Coupler and safety cables are properly connected to tow vehicle
• Flat 4-pin electrical plug is connected to tow vehicle
• Tailgate is up and strapped securely with 24” velcro strap
• Be sure all lights are functioning
• Ring grip pins are secured
• Storage box lid is secured
• Properly secure cargo
