10
GO User Guide
Travel mode - Systems overview
Before departing in your GO, there are a few operations you should familiarize yourself with.
Understanding the safe operation of these systems will reduce chances of injury or damage.
• Lift system
• Stabilizer jacks
• Swivel jack
• Coupler connect/disconnect
• Secure tailgate
• Ring grip pins
Lift system:
The lift system enables you to raise and lower the rack and tent pod assembly between
Travel mode, Transport mode, and Camping mode.
1. Remove all ring grip pins.
2. Remove the winch handle from storage box lid.
3. Insert winch handle into the winch opening.
4. Turning the *winch handle clockwise, raise the rack and tent pod assembly to desired
height. To lower the rack and tent pod assembly, reverse direction (counter clockwise) and
lower to desired height and stop turning at that point.
*Note: The SylvanSport drill adapter, combined with a cordless power drill is a handy device
which can be used to raise the lift system quickly.
Stabilizer jacks:
The stabilizer jacks are mounted under the deck, at all four corners. They are spring loaded
and retracted for traveling. To access each stabilizer jack, kneel at each corner, facing the
center of the GO.
1. Grasp the stabilizer jack and push away from you, toward the center of the GO and allow
the stabilizer jack to drop down into position.
2. Press to release the tab on stabilizer jack and allow the extension leg to drop to the
ground.
3. Using the stabilizer jack adjustment rod, make nal adjustments to stabilize the GO.
Before traveling, make sure all four stabilizer jacks have been returned to their retracted
position.
For details on the stabilizer jack operation, watch GO tutorial videos on our website and/or
YouTube channel.
Turning the winch handle counter clockwise allows the
rack system to lower, it does not pull the rack system
down. The rack system should raise or lower when
turning the crank
