SYM 9. FINAL DRIVING MECHANISM
9-1
MECHANISM DIAGRAM....................9-1
OPERATIONAL PRECAUTIONS .......9-2
TROUBLE DIAGNOSIS......................9-2
DISASSEMBLY OF FINAL DRIVING MECHANISM .........9-3
INSPECTION OF FINAL DRIVING MECHANISM..9-3
BEARING REPLACEMENT................9-4
RE-ASSEMBLY OF FINAL DRIVING MECHANISM.........9-6
MECHANISM DIAGRAM
driving gear
countershaft gear
final driving gear
final driving shaft
countershaft
1.8~2.2 kgf-m
1.0~1.4 kgf-m
3.5~4.5 kgf-m
