Sym FIDDLE 125 User Manual

SYM 4. FUEL SYSTEM
4-1
MECHANISM ILLUSTRATION .............4-1
PRECAUTIONS IN OPERATION .........4-2
TROUBLE DIAGNOSIS........................4-3
CARBURETOR REMOVAL ..................4-4
VACUUM CHAMBER ...........................4-4
AIR CUT-OFF VALVE ..........................4-6
AUTO BY-STARTER.......................... 4-7
FLOAT CHAMBER .............................4-8
INSTALLATION OF CARBURETOR .. 4-9
IDLE SPEED ADJUSTMENT..............4-9
FUEL TANK........................................ 4-10
AIR CLEANER.................................... 4-11
MECHANISM ILLUSTRATION
Carburetor
Fuel strainer
Fuel tank cap
Fuel unit

Sym FIDDLE 125 Specifications

General

Displacement	124.6 cc
Cooling System	Air Cooled
Transmission	CVT
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	110/70-12
Rear Tire	120/70-12
Seat Height	780 mm
Engine Type	4-Stroke
Fuel Tank Capacity	6.5 L
