SYM 16. ELECTRICAL EQUIPMENT
16-1
MECHANISM DIAGRAM ....................16-1
PRECAUTIONS IN OPERATION .......16-2
SPECIFICATION ................................16-3
TROUBLE DIAGNOSIS......................16-4
CHARGING SYSTEM.........................16-5
IGNITION SYSTEM ............................16-11
STARTING SYSTEM..........................16-14
METER ...............................................16-15
LIGHTS/BULBS ..................................16-17
MAIN SWITCH/HORN ........................16-19
FUEL UNIT .........................................16-22
MECHANISM DIAGRAM
Spark plug
Alternator
Fuel unit
Ignition coil
Battery/ fuse box
/C.D.I
Main switch
REG.REC/Horn/
/Resistor
Starter magnetic
switch
Starting/headlight
switch
High & low beam/seat
open/turn signal light/Horn
Auto by-star
Front/Rear stop
switch
Winker relay
Engine start
control switch

Sym FIDDLE 125 Specifications

General

Displacement	124.6 cc
Cooling System	Air Cooled
Transmission	CVT
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	110/70-12
Rear Tire	120/70-12
Seat Height	780 mm
Engine Type	4-Stroke
Fuel Tank Capacity	6.5 L
