Sym FIDDLE 125 User Manual

SYM 12. BODY COVER
12-1
MAINTENANCE INFORMATION........12-2
HANDLE COVER ...............................12-3
FRONT COVER..................................12-4
UNDER COVER .................................12-5
FRONT INNER BOX...........................12-6
BODY COVER/REAR FENDER.........12-7
FRONT CENTER COVER..................12-9
LUGGAGE BOX.................................12-9
FLOOR PANEL ..................................12-9
Front center
cover
Frame number
cover
Left body cover
Inner box
Double Seat
Rear carrier
Luggage box
Floor panel
Front cove
r
Under cover
Rear fender
Rear handle
cove
r
Front fende
r
Right body cover
Battery cover
RR. mudguard
Rear inner
fender
Fuel tank
Front handle
cove
r
Front spoiler
Left side cover
Right side cover

Sym FIDDLE 125 Specifications

General

Displacement	124.6 cc
Cooling System	Air Cooled
Transmission	CVT
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	110/70-12
Rear Tire	120/70-12
Seat Height	780 mm
Engine Type	4-Stroke
Fuel Tank Capacity	6.5 L
