Sym FIDDLE 125 User Manual

12. BODY COVER SYM
12-2
MAINTENANCE INFORMATION
Body covers disassemble sequence:
 Be careful not to damage various covers in disassembly or re-assembly operation.
 Never injure hooks molded on the body covers in disassembly or re-assembly operation.
 Align the buckles on the guards with slot on the covers.
 Make sure that each hook is properly installed during the assembly.
 Never compact forcefully or hammer the guard and the covers during assembly.
Battery cover
Luggage box & Seat
Front center cover
Front handle cover
Floor panel
Rear carrier
Rear fender
Rear handle cover
Front fender
Front cover
Inner box
Left/right body cover
Rear inner fender
Front cushion
Front spoiler
Left/right side cover
Under cover

Sym FIDDLE 125 Specifications

General

Displacement	124.6 cc
Cooling System	Air Cooled
Transmission	CVT
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	110/70-12
Rear Tire	120/70-12
Seat Height	780 mm
Engine Type	4-Stroke
Fuel Tank Capacity	6.5 L
