10. A.C. GENERATOR/STARTING CLUTCH SYM
10-2
PRECAUTIONS IN OPERATION
General information
 Refer to chapter 5: Engine removal and installation
 Refer to chapter 1: The troubleshooting and inspection of A.C. generator
 Refer to chapter 16: The service procedures and precaution items of starter motor
Specification Unit: mm
Item Service Limit
ID of starting driven gear 32.060
OD of starting clutch cover 27.940
Torque value:
Flywheel nut 5.0~6.0kgf-m
Exhaust muffler bolt 8 mm 3.0~3.6kgf-m
Oil screen cover 1.0~2.0kgf-m
Starting clutch hex lock nut 9.0~10.0kgf-m with oil on the thread
Starting clutch hex socket bolt 1.0~1.4kgf-m with adhesive
Special service tools
Flywheel puller
Universal fixture

Sym FIDDLE 125 Specifications

General

Displacement	124.6 cc
Cooling System	Air Cooled
Transmission	CVT
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	110/70-12
Rear Tire	120/70-12
Seat Height	780 mm
Engine Type	4-Stroke
Fuel Tank Capacity	6.5 L
