SYM 3. LUBRICATION SYSTEM
3-1
MECHANISM DIAGRAM....................3-1
OPERATIONAL PRECAUTIONS .......3-2
TROUBLE DIAGNOSIS......................3-2
ENGINE OIL.......................................3-3
CLEANING ENGINE OIL STRAINER...3-3
OIL PUMP ............................................3-4
GEAR OIL ............................................3-7
MECHANISM DIAGRAM
Valve rocker
arm
Camshaft
Scoop lubrication
Forcedly lubrication
Forcedly
lubrication
Inner passage
Connecting rod
Oil pump
Oil strainer
Crankshaft
