Sym FIDDLE 125 User Manual

SYM CONTENTS
CONTENTS
GENERAL INFORMATION/TROUBLE DIAGNOSIS...................................1
MAINTENANCE INFORMATION .................................................................2
LUBRICATION SYSTEM..............................................................................3
FUEL SYSTEM.............................................................................................4
ENGINE REMOVAL......................................................................................5
CYLINDER HEAD/VALVE............................................................................6
CYLINDER/PISTON......................................................................................7
"V" TYPE BELT DRIVING SYSTEM/KICK STARTER ARM .......................8
FINAL DRIVING MECHANISM.....................................................................9
A.C. GENERATOR/STARTING CLUTCH....................................................10
CRANKCASE/CRANKSHAFT .....................................................................11
BODY COVER..............................................................................................12
BRAKE SYSTEM..........................................................................................13
STEERING/FRONT WHEEL/FRONT SHOCK ABSORBER........................14
REAR WHEEL/SUSPENSION......................................................................15
ELECTRICAL EQUIPMENT .........................................................................16
ELECTRICAL DIAGRAM .............................................................................17

Sym FIDDLE 125 Specifications

General

Displacement	124.6 cc
Cooling System	Air Cooled
Transmission	CVT
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	110/70-12
Rear Tire	120/70-12
Seat Height	780 mm
Engine Type	4-Stroke
Fuel Tank Capacity	6.5 L
