MECHANISM ILLUSTRATIONS SYM
Light/starter switch
Front disk brake
Exhaust muffler
Ignition switch
Gea
r
oil draining
bolt
Battery/Fuse/CDI
Front brake lever
Rea
r
brake leve
r
Ai
r
cleane
r
Gea
r
oil filling
bolt
Oil level
Tail light
Front turn
signal light
Fuel tank / Fuel unit
High&Low beam/Seat
open/turn signal/horn
Head light/
Position light
Rear turn
signal light
Engine number/engine
oil draining bolt
Ignition coil
Frame numbe
r
Meter
A.C. Generator
Start magnetic switch
Horn/REG.REC
RR. turning
signal light
Tail light
Front turn
signal light
Winker relay
Engine control
switch
