SPECIAL TOOL
1
ITEM: R/L CRANKCASE DISASSEMBLE TOOL
NO：SYM-1120100
PURPOSE: DISASSEMBLE CRANKCASE
ITEM: CRANK PULLER
NO：SYM-1130000
PURPOSE: INSTALL CRANKCASE
ITEM: OUTER BEARING PULLER
NO：SYM-6204010
PURPOSE: REMOVE THE BEARING
ITEM: ACG FLYWHEEL PULLER
NO：SYM-3110A00
PURPOSE:
REMOVE ACG FLYWHEEL
ITEM: LOCK NUT PULLER
NO：SYM-9020100
PURPOSE:
REMOVE THE LOCK NUT
ITEM: UNIVERSAL HOLDER
NO：SYM-2210100
PURPOSE:HOLD THE MDF/CLUTCH OUTER
