Sym FIDDLE 125 User Manual

11. CRANKCASE/CRANKSHAFT SYM
11-4
Remove the crankshaft from the right
crankcase.
Caution
Remove gasket and dowel pins (2).
Scrape gasket residues off the crankcase
contact surface.
Caution
Remove oil seal from the left crankcase.
 Do not damage contact surface of the
crankcase.
 Soap the gasket residues into solvent
and the residues will be removed
easily.
 The left and right bearings of crankshaft
is to press-fit onto the crankshaft.

Sym FIDDLE 125 Specifications

General

Displacement	124.6 cc
Cooling System	Air Cooled
Transmission	CVT
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	110/70-12
Rear Tire	120/70-12
Seat Height	780 mm
Engine Type	4-Stroke
Fuel Tank Capacity	6.5 L
