15. REAR WHEEL/REAR SHOCK ABSORBER SYM
15-2
PRECAUTIONS IN OPERATION
General Information
As for the wheel removal, service, and installation procedures, please refer to the service
manual of high speed tire.
Specification Unit: mm
Items Standard Limit
Radial - 2.0
Wheel wobbling
Axial - 2.0
Thickness of rear brake lining 4.0 2.0
Torque values:
Rear axle nut 11.0~13.0kgf-m
Rear shock absorber upper mount bolt 3.5~4.5kgf-m
Rear shock absorber lower mount bolt 2.4~3.0kgf-m
Exhaust muffler connection nut 1.0~1.4kgf-m
Exhaust muffler connection bolt 3.0~3.6kgf-m
TROUBLE DIAGNOSIS
Rear wheel wobbling
bend wheel rim
poor tire
loosen wheel shaft
Shock absorber too soft
insufficient shock
absorber spring force
Braking Noise
worn brake lining
brake drum deformation
improperly brake panel
installation
unparalleled brake drum
or wheel unparallel.
Poor brake performance
Poor brake adjustment
contaminated brake
lining
worn brake lining
greased brake drum
contaminated and
seized brake cable
improperly installation of
brake cable
