Sym FIDDLE 125 User Manual

5. REMOVAL OF ENGINE SYM
5-2
OPERATIONAL PRECAUTIONS
General Information
 Engine must be supported by a bracket or adjustable tool in height.
 The following parts can be serviced with the engine installed on the frame.
1. Carburetor
2. Driving disk, driving belt, clutch, and transporting disk
3. Final reduction gear mechanism
Specification
Specification
Disassemble 850 c.c.
Engine Oil Capacity
Replacement 750 c.c.
Disassemble 110 c.c.
Gear Oil Capacity
Replacement 100 c.c.
Torque Values
Engine suspension bolt (frame side) 4.5~5.5kgf-m
Engine suspension nut (engine side) 4.5~5.5kgf-m
Bolt of rear shock absorber upper connection 3.5~4.5kgf-m
Bolt of rear shock absorber lower connection 2.4~3.0kgf-m

Sym FIDDLE 125 Specifications

General

Displacement	124.6 cc
Cooling System	Air Cooled
Transmission	CVT
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	110/70-12
Rear Tire	120/70-12
Seat Height	780 mm
Engine Type	4-Stroke
Fuel Tank Capacity	6.5 L
