14
OIL CHANGE:
Change engine oil after the first 300km, and change the
engine oil every 1000km thereafter.
In order to maintain the engine’s maximum
performance, check whether the engine oil is enough
every 500km. Add oil to upper limit if the engine oil
has been found to be inadequate.
Engine Oil : Use (API) SH/CD SAE 10W-30 grade or
better engine oil. Otherwise, damage will not be
covered by warranty.
※ Recommended Oil: SYM Genuine 4X OIL.
Oil Capacity : 0.95 Liter (0.70 liter for routine change).
Oil Capacity : 1.00 Liter (0.80 liter for routine change.
For:XC12WW-EU)
Use SAE 5W-40 when outside temperature is below 0℃.
【Oil Filter Cleaning】
The oil filter nut assembly of the element, and remove the
element. Remove the foreign materials from the element by
using a gasoline or air spraying gun.
§FUEL INSPECTION§
Turn main switch key to “ON” position, and check fuel gauge’s needle range to make sure there
is enough amount of fuel in the fuel tank.
This scooter’s engine is designed for using the unleaded fuel of Octane 90 or above.
Firmly secure the main stand on the ground, shut off the engine and keep flames away from the
scooter when refueling.
Do not fill above fuel upper limit lever when refueling.
Make sure the fuel tank cap had been tighten properly.
§TRANSMISSION OIL INSPECTION AND CHANGE§
INSPECTION:
Use the main stand to support the scooter on a level ground, after the engine stops, wait for 3~5
minutes. Remove the transmission oil infusion bolt, put a measuring glass under the drain bolt,
and remove the drain bolt. Let the oil flows into measuring glass and check for decreased or not.
(at disassembly:180c.c./at change:170c.c.For:XC12WW-EU:190c.c./at change:180c.c)
OIL REPLACEMENT:
Stop the engine and use the main stand to support your scooter on a lever ground. Remove the
infusion bolt and drain bolt, drain out the oil.
Install the drain bolt and tighten it. Fill new transmission oil (170c.c.), and install the infusion bolt
and tighten it. (make sure that bolts are tightened and check that there’s no leakage.)
Recommend Oil: Genuine SYM HYPOLD GEAR OIL (SAE 85W-140)
WARNING:
Oil level will not be correct when checking the oil level
with the motorcycle parked on an unleveled ground or
immediately after the engine stopped.
Engine and exhaust pipe are hot right after engine
stopped. Pay special attention not to get burned
when checking or replacing engine oil.
If the oil lever approach lower limit again after refilled,
check the engine for leaks and refill it again.
Keep away from spark and flames when refilling the
oil.
