7.
USE OF EACH COMPONENT
(The following is SYM 4 stroke air-cooling125c.c./200c.c.scooter’s basic operation, and
they could vary from different individual models. Please consult the end of this manual.)
§GAUGES §
Speedometer/ Tachometer：
Indicates driving speed or engine rpm.
Odometer:
Indicates total accumulated distance traveled.
Trip Kilometer:
The rider can measure the trip kilometers.
In normal display status, press “MODE” button for 1second,it can show total distance traveled.
Press “MODE” button again, then it can switching over trip kilometer display mode.
In trip kilometer display status, press "SET" button for a long time, it can eliminate the mileage value.
High Beam Indicator：
This indicator comes on with high beam headlight is turned on.
Turn (left/right) Signal Indicator：
The left or right Indicator will be flashing according to the operated directions of turn signal light
switch when it is turned on.
Fuel Meter:
The pointer in this meter shows how much fuel remains in the tank.
The pointer stays in “E” position when key switch is turned to “OFF”.
Cooling temperature indicator(For:XC12WW-EU):
Indicates the engine cooling water temperature, engine cooling water temperature indicator if light,
should check the cooling water is sufficient and the fan motor is running.
Voltmeter/time(For:XC12WW-EU/XC20W1-EU):
Display average voltage of battery or time.
Under the normal display status, press "SET" button 0.5 second, it can switch “VOLTAGE” display
