17. SPECIFICATION
Model
XC12WW-EU
Item
Specification
Length
1990 mm
Width
730 mm
Height
1075/1115(with visor) mm
Wheel base
1350mm
Net Weight
135kg(front 53kg rear 82kg)
Model
Single cylinder,4- stroke, forced liquid cooled engine
Fuel required
Unleaded gasoline
Displacement
124.65 c.c.
Compression ratio
11.3±0.2 :1
Maximum HP
8.3kw/8000 rpm
Maximum torque
10.7N.m/6500 rpm
Valve clearance: IN/EX
0.12/0.12 mm
Starting methods
Electrical starter
Front shock absorber
Telescopic fork
Rear shock absorber
Single
Transmission
C.V.T.
Front tire
100/90-14
Rear tire
110/80-14
Rim type
Aluminum
Tire pressure
Front: STD 2.00 kg/cm
2
,
Rear: STD 2.00kg/cm
2
for 1 person, 2.25kg/cm
2
for 2 persons
Front brake
Disk type
Rear brake
Disk type
Head lamp(high, low)
12V 35/35W
Front position lamp
12V LED 0.5W
Front/ Rear direction indicator
12V 10W/12V 10W
Rear position lamp
12V LED 0.5W
Taillight/Stop lamp
12V LED 0.12W/2.0W
Engine oil capacity
1.00 L (0.80 L for change)
Transmission oil capacity
190c.c (180c.c for change)
Fuel tank capacity
7.50L
Fuse
15A×2 &10A×1 & 20A×1
Spark plug
CR7HSA
Battery capacity
12V 6Ah(closed type, maintenance-free battery)
Air cleaner
Paper type
