18. SPECIFICATION
Model
XC20W1- ZA/XC20W-ZAC/XC20W1-EU
Item
Specification
Length
1990mm
Width
730mm
Height
1075/1115(with visor) mm
Wheel base
1350mm
Net Weight
134kg(front 53kg rear 81kg)
Model
Single cylinder,4- stroke, forced air cooled engine
Fuel required
Unleaded gasoline
Displacement
168.9 c.c.(Bore:61mm Stroke:57.8mm)
Compression ratio
10.16±0.2 :1
Maximum HP
8.8kw/8000 rpm
Maximum torque
12.2N.m/6000 rpm
Valve clearance: IN/EX
0.12/0.12 mm
Starting methods
Electrical starter
Front shock absorber
Telescopic fork
Rear shock absorber
Double swings
Clutch type
Auto centrifugal type
Transmission
C.V.T.
Front tire
100/90-14
Rear tire
110/80-14
Rim type
Aluminum
Tire pressure
Front: STD 2.00 kg/cm
2
,
Rear: STD 2.00kg/cm
2
for 1 person, 2.25kg/cm
2
for 2 persons
Front brake
Disk type (Ø 260 mm)
Rear brake
Disk type (Ø 220 mm)
Head lamp(high, low)
12V 35/35W
Front position lamp
12V LED 0.5W
Front/ Rear direction indicator
12V 10W/12V 10W
Taillight /Stop lamp
12V LED 0.12W/2.0W
Engine oil capacity
0.95 L (0.70 L for change)
Transmission oil capacity
180c.c (170c.c for change)
Fuel tank capacity
7.50L
Fuse
15A×2 &10A×1 & 20A×1
Spark plug
CR7HSA
Battery capacity
12V 6Ah(closed type, maintenance-free battery)
Air cleaner
Paper type
