Sym JET 14 XC05W1-EU Series User Manual

31
19. SPECIFICATION
Model
XC05W1-EU
XC05W1-NL
Item
Specification
Length
1990mm
Width
730mm
Height
1075/1115(with visor) mm
Wheel base
1330mm
Net Weight
119kg(front48kg rear 71kg)
Model
Single cylinder,4- stroke, forced air cooled engine
Fuel required
Unleaded gasoline
Displacement
49.46 c.c.(Bore:37mm Stroke:46mm)
Compression ratio
12.6±0.2 :1
Maximum HP
2.6kw/7500 rpm
2.2kw/6500rpm
Maximum torque
3.5N.m/6500 rpm
3.3 Nm/6500 rpm
Valve clearance: IN/EX
0.05±0.02/0.05±0.02 mm
Starting methods
Electrical starter
Front shock absorber
Telescopic fork
Rear shock absorber
Double or single
Clutch type
Auto centrifugal type
Transmission
C.V.T.
Front tire
100/90-14
Rear tire
110/80-14
Rim type
Aluminum
Tire pressure
Front: STD 2.00 kg/cm
2
,
Rear: STD 2.00kg/cm
2
for 1 person, 2.25kg/cm
2
for 2 persons
Front brake
Disk type (Ø 260 mm)
Rear brake
Drum type (Ø 110 mm)
Head lamp(high, low)
12V 35/35W
Front position lamp
12V LED 0.5W
Front/ Rear direction indicator
12V 10W/12V 10W
Taillight /Stop lamp
12V LED 0.12W/2.0W
Engine oil capacity
0.8 L (0.65 L for change)
Transmission oil capacity
110c.c (100c.c for change)
Fuel tank capacity
7.50L
Fuse
2AX1 &5A×1 & 10A×1 &15AX1
Spark plug
CR6HSA
Battery capacity
12V 6Ah(closed type, maintenance-free battery)
Air cleaner
Paper type
