17. ELECTRICAL SYSTEM
17-12
Meters
Removal
Loosen 4 bolts of the meter stay.
Remove the front center cover, and then remove
meter couplers and main switch coupler.
Remove speedometer cable.
Remove speedometer cable, and then remove
meter set, main switch and handle cover
Remove 4 nuts and meter wire, and then remove
speedometer and fuel meter.
To this chapter contents
4 nuts
Each side 2 bolts
Main switch coupler
Meter set couplers
Speedometer cable
