17. ELECTRICAL SYSTEM
17-13
Light / Bulb
Replacing Bulb for Headlight
Remove 4 screws for the headlight cover, and
remove the cover.
Loosen headlight bulb setting plate screw.
Remove bulb setting hook.
Take out the bulb connector and the bulb.
Replace with new bulb if necessary.
(H7 12V 55W)
Caution
y Never touch the bulb with finger, which will
create a heat point.
y Clean the fingerprint left on the bulb with
alcohol.
Install the bulb of the headlight in reverse order of
removal.
Upon completion of replacement, turn on the main
switch to ensure the headlight works well.
Adjust the beam and distance of the headlight if
necessary.
To this chapter contents
1 screw
4 screws
Adjustment screw
1 screw
Hook
