Sym Symphony ST XB05W4-EU Series User Manual

26
Model
XB12W2-EU (SYMPHONY ST 125i)
Item
Specification
Length
1995mm
Width
725mm
Height
1195mm
Wheel base
1350mm
Net Weight
120kg(front 47kg rear 73kg)
Model
Single cylinder,4- stroke, forced air cooled engine
Fuel required
Unleaded gasoline
Displacement
124.6 c.c.(Bore:52.4mm Stroke:57.8mm)
Compression ratio
10.68±0.2 :1
Maximum HP
7.5kw/8500 rpm
Maximum torque
9.2N.m/7000 rpm
Valve clearance: IN/EX
0.12/0.12 mm
Starting methods
Electrical starter
Front shock absorber
Telescopic fork
Rear shock absorber
Double swings
Clutch type
Auto centrifugal type
Transmission
C.V.T.
Front tire
110/70-16
Rear tire
110/70-16
Rim type
Aluminum
Tire pressure
Front: STD 2.00 kg/cm
2
,
Rear: STD 2.00kg/cm
2
for 1 person, 2.25kg/cm
2
for 2 persons
Front brake
Disk type (Ø 260 mm)
Rear brake
Disk type (Ø 240 mm)
Head lamp(high, low)
12V 35/35W
Front position lamp
12V LED
Front/ Rear direction indicator
12V 10W
Rear position lamp/Stop lamp
12V 1.7W/12V 0.1W
Engine oil capacity
0.95 L (0.80 L for change)
Transmission oil capacity
180c.c (170c.c for change)
Fuel tank capacity
7.50L
Fuse
10A×2 &15A×1 & 20A×1
Spark plug
CR7HSA
Battery capacity
12V 6Ah(closed type, maintenance-free battery)
Air cleaner
Paper type

Sym Symphony ST XB05W4-EU Series Specifications

General

Brand	Sym
Model	Symphony ST XB05W4-EU Series
Category	Scooter
Language	English
