15. SPECIFICATION
Model
XB05W4-EU/NL (SYMPHONY ST 50)
Item
Specification
Length
1985mm
Width
725mm
Height
1195mm
Wheel base
1330mm
Net Weight
117kg(front 45kg rear 72kg)
Model
Single cylinder,4- stroke, forced air cooled engine
Fuel required
Unleaded gasoline
Displacement
49.46 c.c.(Bore : 37mm Stroke : 46mm)
Compression ratio
12.6±0.2 :1
Maximum HP
2.6kw/7500 rpm / 2.2kw/6500 rpm
Maximum torque
3.5Nm/6500 rpm / 3.3Nm/6500 rpm
Valve clearance: IN/EX
0.10/0.10 mm
Starting methods
Electrical starter
Front shock absorber
Telescopic fork
Rear shock absorber
Unit swing
Clutch type
Auto centrifugal type
Transmission
C.V.T.
Front tire
110/70-16
Rear tire
110/70-16
Rim type
Aluminum
Tire pressure
Front: STD 2.00 kg/cm
2
,
Rear: STD 2.00kg/cm
2
for 1 person, 2.25kg/cm
2
for 2 persons
Front brake
Disk type (Ø 260 mm)
Rear brake
Disk type (Ø 240 mm)
Head lamp(high, low)
12V 35/35W
Front position lamp
12V LED
Front/ Rear direction indicator
12V 10W
Rear position lamp/Stop lamp
12V 1.7W/12V 0.1W
Engine oil capacity
0.80 L (0.70 L for change)
Transmission oil capacity
180c.c (170c.c for change)
Fuel tank capacity
7.50L
Fuse
2A×1 &5A×1 & 10A×1 &15A x 1
Spark plug
CR6HSA
Battery capacity
12V 6Ah(closed type, maintenance-free battery)
Air cleaner
Paper type
