Symmetricom ET6000 User Manual

CHAPTER TWO
Figure 2-4
Antenna/Preamp Installation
5000-0001
Bullet Antenna
(Mfg P/N 25045-10)
1704-9389 Type F
to Type N Connector
Adapter
Antenna Mast 711700:
Secure to an existing vent pipe using hose
clamps or secure to a flat surface using
pipe straps and screws.
Antenna Cable with
Type N Connector
Note: The GPS antenna and cable described in this manual have been replaced as described in
“Appendix D: Antenna Replacement Kit” on page D-1.
2-10 ET6xxx ExacTime GPS TC & FG (Rev C) Symmetricom Inc
