SYSMEX CyFlow Space User Manual

42
C
y
Flow
™
Space
|
Operatin
g
Manual
|
March 2021
Calibration Beads UV 2.5 µm Concentrate
(05-4022)
Violet laser:
Calibration Beads 3 µm (05-4018)
Set-up Time 2-4 minutes
Parameters as Analyser Up to 16 optical parameters: FSC1, FSC 2,
SSC, FL1-FL13; Time parameter, pulse
height (P-H), pulse area (P-A), pulse width
(P-W) for two optical parameters
With cell sorting option
Up to 8 optical parameters: FSC, SSC,
FL1-FL6; Time parameter, pulse height (P-
H), pulse area (P-A), pulse width (P-W) for
two optical parameters
Particle Size Range 0.1 µm - 100 µm
Maximum Acquisition Speed 25.000 events/sec
Acquisition Stop Time Time-, event- or volume-based
Trigger
On all parameters or on specific trigger
parameter, selectable by software
Data Resolution 65,536 channels (16 bit)
Service
Please contact your local Sysmex
representative
12.2 Optics
Light Sources:
Laser / Output
Laser specifications may be subject to change.
Red Diode Laser: 25 mW or 40 mW at 638
nm/640 nm
Green solid-state Laser: 30 mW or 100
mW at 532 nm
Blue Diode Laser: 50 mW
Blue solid-state laser: 30 - 200 mW at 488
nm
Violet Diode Laser: 100 mW at 405 nm
Ultra Violet Diode: 60 mW at 375 nm
Yellow Diode Laser: 100 mW at 561 nm
Orange Diode Laser: 50 mW at 594 nm
LED UV-LED 365 nm
Detectors Analyser 1 to 16 (FSC1, FSC2, SSC, FL1 – FL13)
Flow cytometer + cell sorting option 1 to 8 (FSC, SSC, FL1, FL2, FL3, FL4, FL5,
FL6)
Filters depending on the individual instrument
configuration
Video Flow Monitor Colour CMOS camera for video flow
monitor
