V/D
S
ERIES
M
ECHANICAL ASSEMBLIES
Revision: 2.1 3-81
Replacing the exhaust filter cartridge
The exhaust filter cartridge should be replaced after approx.
150 sterilisation cycles.
The Repl. Filter message appears in the display at the appropriate
time.
NOT READY
Repl. Filter
1
1
Yes No Exit
Fig. 43: Filter replacement message
• Press the No button. The selected program starts and the cycle
counter continues counting. The message Repl. Filter now
appears every time a cycle is started.
• Press the Yes button: The exhaust filter cartridge is replaced as
described below. The cycle counter is reset to 0. Confirm the filter
change by entering the code for access level 1.
Replacement (not on D-23)
The exhaust filter cartridge is located in a filter housing at the front left and
is sealed by a white plastic cover.
Safety measures during replacement
Wear protective clothing and dispose of the exhaust filter
cartridge in accordance with the applicable on-site health and
safety regulations.
• To replace the filter cartridge, unscrew the three screws on the cover
and remove it.
• Remove the filter cartridge from the housing using the tool (pliers)
supplied and insert the new filter cartridge.
• Screw the cover back on.
