V/D
S
ERIES
M
ECHANICAL ASSEMBLIES
Revision: 2.1 3-37
Digital inputs on the door control
The following status table provides an overview of the digital input values
when the door is open and closed:
As the same device software is used on 40 – 55 l devices as on > 65
devices, the switch settings on the digital inputs are shown as ring
positions (see Fig. 13: oben).
Door Close switch
The status of the Door Close switch is only used to trigger the
closing process and is then no longer queried.
The Door Close switch can therefore be open during the
process after the door is locked.
Digital inputs Door
open
Door
closed
Door Close
/
Ring Open
Ring Close
Gasket SW
Ring Close 2
Ring Close 3
Ring Close 4
Tab. 8: Status table for the digital inputs when the door is open and closed
(: Off, : On)
Maintenance tasks
Replacing a locking cylinder
Necessary
tools
– 7 mm spanner
– Suitable pliers and a cloth to protect the surface, when necessary
Have
available
– White adhesive, Systec item no. 11920
• Remove the door cladding (see chapter 3.4.1 unterhalb).
• Secure the piston rod of the cylinder with the spanner and turn the
locking bolt anti-clockwise with the pliers to remove it.
Do not scratch the locking bolt!
Do not scratch the surface of the locking bolt. If it becomes
scratched, grind it smooth and polish it.
