V/D
S
ERIES
R
EGULAR TESTS AND MAINTENANCE
Revision: 2.1 5-7
Lift option
The function of the lift is described in chapter 3.17, “Lift”.
Column Check for firm seating Chapter 3.17
Function Pay attention to the
travel direction
Chapter 3.17
Arm and basket support Check for firm seating Chapter 3.17
Tab. 12: Maintenance work on the lift
Vacuum unit option
The function of the vacuum unit is described in detail in chapter 3.11,
“Vacuum unit (optional)”.
Vacuum pump Check performance and
build-up of noises, fill
using a container
marked in litres
Chapter 3.11.2,
“Checking water usage”
Sterile air filter Check and replace, if
necessary
Chapter 3.7.2,
“Replacing the sterile air
filter”
Vacuum valve Check function, check
for leaks
Chapter 3.11
Chapter 6.2.8
Pump water valve for vacuum
pump
Check Chapter 3.11.2,
“Checking water usage”
Vacuum test Execute Chapter 3.11.2
Testing the sterilisation
chamber for leaks –
vacuum test
Tab. 13: Maintenance work on vacuum unit
Exhaust filter option
The function of the exhaust filter is described in detail in chapter 3.16,
“Exhaust filter”.
Counter value on exhaust filter Check
If necessary, replace
filter earlier
Chapter 3.16.2,
“Checking the counter
value”
When replacing filter Reset counter Chapter 3.16.2,
“Replacing the exhaust
filter cartridge”
Tab. 14: Maintenance work on the exhaust filter
