Template 4: Dual Hazard - Split Release FACP Configuration Templates
B.4 Template 4: Dual Hazard - Split Release
Table Legend:
X = direct correlation between Input Zone and Output Circuit (input zone activation will turn on
corresponding output circuit).
Input Zone Types:
• Zone 1 = 2-wire smoke
• Zone 2 = Fire
• Zone 3 = Waterflow - activation delayed for 10 seconds (Waterflow Delay Timer 10 set to
secs.)
• Zone 4 = Supervisory
• Zone 5 = Manual Release
• Zone 6 = Pull Station
Output Circuit Types:
• Output 1 = Alarm NAC, silenceable, coded for steady on
• Output 2 = Supervisory Bell NAC, silenceable, coded for steady on
• Output 3 = Release Solenoid 1 (unsupervised for shorts)
• Output 4 = Release Solenoid 2 (unsupervised for shorts)
Timers
• Soak Timer 1 - set for 10 minutes
• Soak Timer 2 - set for 10 minutes
• Waterflow Delay Timer - set for 10 seconds
• AC Loss Delay Timer - set for 2 hours
Operation
• Activation of Input Zone 1 (2-Wire Smoke) will operate Release Solenoid 1 Output #3 and
Alarm NAC Output #1. Activation of Input Zone 2 (Fire) will operate Release Solenoid 2 Out-
put #4 and Alarm NAC Output #1. Activation of Input 5 (Manual Release) or Input 6 (Manual
Pull Station) will operate Solenoid 1 Output #3 and Solenoid 2 (Output #4) and Alarm NAC
Output #1. Release Solenoid 1 will turn off water release following time-out of the 10 minute
Soak Timer 1 and Release Solenoid 2 will turn off water release following time-out of the 10
minute Soak Timer 2
• Activation of Input Zone 3 (Waterflow) will operate the Alarm NAC Output #1. There is a 10
second FACP initiated delay in activation since Waterflow Delay Timer is set to 10 seconds
• Activation of Input Zone 4 (Supervisory) will operate the Supervisory Bell NAC Output #2
Template 4: DUAL HAZARD - SPLIT RELEASE
INPUT ZONES
123456
OUTPUT CIRCUITS
2-WIRE SMOKE FIRE WATERFLOW SUPV.
MANUAL
RELEASE
PULL
STATION
#1 ALARM NAC
XXX XX
#2 SUPV BELL NAC
X
#3 RELEASE SOLENOID 1
XXX
#4 RELEASE SOLENOID 2
XXX
