PDRP-2001 Series Manual — P/N 53043:E4 7/28/2016 85
Read Status Operating Instructions
Pressing 1 for Release 1 or 2 for Release 2 will display the cross-zoning, if any, for the selected
Releasing Circuit as illustrated in the following screen:
The Cross Zone Release screen displays the zones that have been cross-zoned. In this example,
Zone 1 is cross-zoned with Zone 4.
4.15.5 On-Board Relays
Pressing 2 while viewing Read Status Screen #2 will display the following screen:
To view the information about a relay, press the number key corresponding to the desired relay.
The following screen will be displayed:
4.15.6 System Settings
Pressing 3 while viewing Read Status Screen #2 will display the following screens:
The operator can view the system settings options that have been programmed into the FACP.
4.15.7 Timers
Pressing 1 while Read Status Screen #3 will display the following screens:
These screens allow the operator to view the various timer settings.
4.15.8 Daylight Savings
Pressing 2 while Read Status Screen #3 will cause the following screens to be displayed:
These screens allow the operator to view settings that have been programmed for Daylight Savings
Time.
CROSS ZONE REL 1
X 1 4
NONE
NONE
Cross Input Zone Screen
ON-BOARD RELAYS
1=RELAY 1
2=RELAY 2
3=RELAY 3
RELAY #
TYPE ALARM
LATCHING NO
SYSTEM SETTINGS
FACTORY BANNER
SYSTEM SETTINGS
FUTURE USE
TROUBLE REMIND NO
CHARGER DISABLE NO
SYSTEM SETTINGS
CANADIAN OPTION NO
SEC ANN ENABLE NO
READ STATUS
1=TIMERS
2=DAYLIGHT SAVINGS
3=HISTORY
Read Status Screen #3
TIMERS
SOAK 1 10 MIN
SOAK 2 10 MIN
WATERFLOW DELAY 0S
TIMERS
AC LOSS DELAY 2 HR
DAYLIGHT SAVINGS
ENABLED YES
START MONTH MAR
START WEEK WK 2
DAYLIGHT SAVINGS
END MONTH NOV
END WEEK WK 1
