PDRP-2001 Series Manual — P/N 53043:E4 7/28/2016 57
Master Programming Level Programming
Strobe NAC
Supv Bell NAC
Trouble Bell NAC
Press the number key corresponding to the desired Output Type to program the selected Output.
Release Circuit 1 or Release Circuit 2
If Release Circuit 1 or Release Circuit 2 is selected as the Output Type, the following subscreen
will be displayed:
This screen allows the programmer to select whether or not to supervise the Releasing Circuit
Output for shorts.
• UNSUPV SHORTS - this option should normally be selected when a releasing solenoid is
connected to the output so the solenoid coil is not supervised for shorts
• SUPV SHORTS - this option, which supervises for shorts, should only be selected when the
REL-4.7K option is installed in series with the solenoid coil
Release Stage NAC
If Release Stage NAC is selected as the Output Type, the following subscreen will be displayed:
An NAC can be used to signal the stages of a release operation. This screen allows the programmer
to select the NAC output that will indicate the release stages for Release Circuit 1 or Release
Circuit 2. For a description of this feature, refer to “Release Stages” on page 81.
Silence
Pressing 1 while viewing Output Screen #2 will cause the following screen to be displayed:
Pressing 1 while viewing the Silenceable Screen #1 will program the selected Output as a
silenceable circuit. This will allow the Output to be silenced by pressing the Alarm Silence key or
by the Auto Silence feature.
Pressing 2 while viewing the Silenceable Screen #1 will program the selected Output as a
nonsilenceable circuit. This will prevent the selected main circuit board Output from being
silenced by pressing the Alarm Silence key or by the Auto Silence feature.
Pressing 3 while viewing the Silenceable Screen #1 will program the selected Output for Stage
Silenceable. This option is used for Release Stage NACs or cross-zone coding NACs. These
NACs will be non-silenceable until its associated Release Circuit has finished discharging, after
which the NAC will become silenceable.
EDIT RELEASE CIR #
1=UNSUPV SHORTS
2=SUPV SHORTS
NOTE: Release circuits may be directly activated by a single input zone or may be activated
using cross-zoned inputs. Refer to “Circuit Mapping and Cross-Zoning” on page 91 for a
description of cross-zoning and input to output circuit mapping.
RELEASE STAGES
1=RELEASE 1 ONLY
2=RELEASE 2 ONLY
OUTPUT #
1=SILENCE NON-SIL
2=AUTO SILENCE NO
3=SIL INHIBITED NO
Output Screen #2
SILENCEABLE
1=SILENCEABLE
2=NON SILENCEABLE
3=STAGE SILENCEABLE
Silenceable Screen #1
SILENCEABLE
1=SYNC MUTE
Silenceable Screen #2
To Next Page
