48 PDRP-2001 Series Manual — P/N 53043:E4 7/28/2016
Section 3: Programming
3.1 User Programming
The FACP is completely field programmable using the panel keypad and requires no special
software skills. While programming the FACP, the fire protection capabilities of the control panel
are
enabled. Programming Mode times-out after 10 minutes of inactivity.
Program Templates have been provided to allow the panel to be quickly programmed with typical
job-site configurations. Refer to “Circuit Mapping and Cross-Zoning” on page 91 for an
explanation of mapping and cross-zoning and “FACP Configuration Templates” on page 96 for a
detailed description of each template.
Site-specific programming may be accomplished:
• by Manual programming or editing, using the FACP keypad
The System All Normal screen will be displayed in a programmed system with no active alarms,
troubles or supervisories, as illustrated below:
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION AND OTHER INVOLVED PARTIES
This product incorporates field-programmable software. In order for the product to comply with the requirements in the
Standard for Control Units and Accessories for Fire Alarm Systems, UL 864, certain programming features or options must be
limited to specific values or not used at all as indicated below.
Program feature or
option
Permitted in UL 864? (Y/N) Possible settings Settings permitted in UL 864
N-ANN-80 Lock Enable Y Lock Enable Yes
Lock Enable No
Refer to Lock Enable in “ANN-80
Options” on page 69
Lock Enable Yes
Combo Y Refer to Table 3.1 on page 52. One Waterflow and one
Supervisory device
Combo w/AutoResettable
Superv
Y Refer to Table 3.1 on page 52. One Waterflow and one
Supervisory device
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION AND OTHER INVOLVED PARTIES
This product incorporates field-programmable software. In order for the product to comply with the requirements in
CAN/ULC-S527, Standard for Control Units for Fire Alarm Systems, certain programming features or options must be limited to
specific values or not used at all as indicated below.
Program feature or
option
Permitted in ULC-S527?
(Y/N)
Possible settings
Settings permitted in
ULC-S527
Release Circuit Short
Supervision
Y UNSUPV Shorts
SUPV Shorts
Refer to “Release Circuit 1 or Release
Circuit 2” on page 57.
SUPV Shorts
Canadian Option Y ON
OFF
Refer to “Canadian Option” on page 66.
ON
SYSTEM ALL NORMAL
10:00A 091814
