20 PDRP-2001 Series Manual — P/N 53043:E4 7/28/2016

Installation Backbox Mounting

mounting studs

mounting slots

mounting tabs

mounting holes

grounding stud:

attach solid earth

ground wire (refer to

Figure 2.4 on page 23)

Board on Chassis

Backbox

Figure 2.1 Chassis Mounting in Backbox

rp2001brdinbox.wmf

mounting slots
