SystemAir SysAqua Series

English
8 SysAqua
8. TECHNICAL SPECIFICATIONS
8.1. PHYSICAL CHARACTERISTICS
(1) according to Eurovent.
45 55 65 75 90 105 125
Supply voltage
400V / 3~ N / 50Hz
Number of refrigerang circuit
1
REFRIGERANT
Type
R410A
Factory charge
SEE NAME PLATE
COMPRESSORS
Type
Scroll
Number
2 2 2 2 2 2 2
Startup type
DIRECT
Part load steps %
0/50/100
0/43/
57/100
0/40/
60/100
0/45/55/100
0/38/
62/100
0/33/
67/100
Crankcase heater W
2x66 2x66 2x66 2x66 66/82 66/95 66/95
EVAPORATOR
Type
plates
Number
1
Water volume L
4.1 4.1 6.1 6.1 10.8 10.8 10.8
Cooling Only
water ow
nominal
m
3
/h
8.57 9.79 11.99 13.03 16.67 19.37 22.32
minimum
5.40 6.17 7.55 8.21 10.50 12.20 14.06
maximum
14.31 16.35 20.02 21.76 27.84 32.35 37.27
Water pressure losses kPa
30 40 31 37 29 38 50
Heat
Pump
Cooling
mode
water ow
nominal
m
3
/h
8.06 9.18 11.30 12.31 15.73 18.25 20.95
minimum
5.08 5.78 7.12 7.76 9.91 11.50 13.20
maximum
13.46 15.33 18.87 20.56 26.27 30.48 34.99
Water pressure losses kPa
27 35 28 33 26 34 45
Heating
mode
water ow
nominal
m
3
/h
8.35 10.01 11.56 13.07 15.16 17.39 20.48
minimum
5.26 6.31 7.28 8.23 9.55 10.96 12.90
maximum
13.94 16.72 19.31 21.83 25.32 29.04 34.20
Water pressure losses kPa
29 39 29 37 23 30 41
Antifreeze electric heater W
30 30 2x30 2x30 2x30 2x30 2x30
FANS
Type
AXIAL
Number
1 1 2 2 2 2 2
STD
Speed tr/mn
790 790 650 650 790 790 790
Air ow rate m
3
/h
22 500 22 500 15 000 15 000 21 000 21 000 21 000
Input power W
1 650 1 650 930 930 1 650 1 650 1 650
HPF
Speed tr/mn
890 890 870 870 890 890 890
Air ow rate m
3
/h
21 000 21 000 16 000 16 000 20 000 20 000 20 000
Input power W
1 950 1 950 1 950 1 950 1 950 1 950 1 950
Static Pressure Pa
100 100 130 130 100 90 90
COILS
Number
1 1 2 2 2 2 2
Frontal surface m²
4.20 4.20 5.55 5.55 6.40 6.40 6.40
Number of rows
2 2 2 2 2 3 3
HYDRAULIC LINKS
Type
Male gas threaded
Inlet diameter pouce
2" 2" 2" 2" 2" 1/2 2" 1/2 2" 1/2
Outlet diameter pouce
2" 2" 2" 2" 2" 1/2 2" 1/2 2" 1/2
BUFFER TANK (OPTION)
Volume L
300 300 300 300 300 300 300
ACOUSTICAL DATA
Sound power level (1)
STD dB(A)
80 80 80 80 83 83 83
HPF dB(A)
81 81 82 82 84 84 84
XLN dB(A)
77 77 77 77 79 79 79
