English
18 SysAqua
11. WIRING DIAGRAM AND LEGEND
N805
11.1. WIRING DIAGRAM
SEE APPENDIX
11.2. LEGEND
11.2.1. POWER SUPPLY
POL 423.50 POL 688
SE4630 SE4746 models 45 to 55 Control Mono 230V 50Hz +/- 10%
SE4629 SE4745 models 45 to 55 Power Tri 400V+N 50Hz +/- 10%
SE4632 SE4748 models 65 / 75 Control Mono 230V 50Hz +/- 10%
SE4631 SE4747 models 65 / 75 Power Tri 400V+N 50Hz +/- 10%
SE4634 SE4750 models 90 / 105 / 125 Control Mono 230V 50Hz +/- 10%
SE4633 SE4749 models 90 / 105 / 125 Power Tri 400V+N 50Hz +/- 10%
SE4636 SE4752 models 45 to 55 all seasons Control Mono 230V 50Hz +/- 10%
SE4635 SE4751 models 45 to 55 all seasons Power Tri 400V+N 50Hz +/- 10%
SE4638 SE4754 models 65 to 75 all seasons Control Mono 230V 50Hz +/- 10%
SE4637 SE4753 models 65 to 75 all seasons Power Tri 400V+N 50Hz +/- 10%
SE4728 SE4778 models 65 to 75 all seasons + HPF Control Mono 230V 50Hz +/- 10%
SE4727 SE4777 models 65 to 75 all seasons + HPF Power Tri 400V+N 50Hz +/- 10%
SE4640 SE4756 models 90 / 105 / 125 all seasons Control Mono 230V 50Hz +/- 10%
SE4639 SE4755 models 90 / 105 / 125 all seasons Power Tri 400V+N 50Hz +/- 10%
SE4641 SE4757 models 45 to 125 Soft Starter Power Tri 400V+N 50Hz +/- 10%
SE4711 SE4758 models 45 to 125 Variable flow simple pump Power Tri 400V+N 50Hz +/- 10%
SE4712 SE4759 models 45 to 125 Variable flow double pump Power Tri 400V+N 50Hz +/- 10%
The supply is protected at the head by an FFG main fuse holder supplied by the installer. It must be tted
next to the unit. Refer to the § ELECTRIC SPECIFICATIONS, page 10
The electrical installation and wiring of this unit must comply with local electrical installation standards.
² Three phase 400 V~ 50Hz + Neutral + Ground :
On the L1, L2, L3, N terminals of the QG section switch
On the ground screw of the earth cable.
² Three phase 400 V~ 50Hz + Ground :
On the L1, L2, L3 terminals of the QG section switch
On the ground screw of the earth cable.
Power cable must be connected to the main power supply switch QG (Copper cable is recommended).
11.2.2. WIRING DIAGRAM KEY DESCRIPTIONS
SEE APPENDIX
