Page 10 Nano ITC Getting Started Guide
The Nano Isothermal Titration Calorimeter (ITC)
The Nano ITC (shown in the figure below) consists of the measuring unit (calorimeter block and two non-
removable reaction vessels), the buret assembly, which includes the stirring system, and a cleaning acces-
sory. With the exception of the power on/off switch located on the back of the calorimeter unit, all func-
tions of the Nano ITC are controlled remotely by the computer through the USB connection.
Figure 1 Nano ITC
2G
.
Applications
Batch/Incremental Titration
In incremental or continuous titration, one of the reactants is placed in a syringe or buret external to the
reaction vessel. If individual, repeated injections are made, incremental titration takes place (as seen in the
example below); if only one injection is made, it is continuous injection calorimetry.
Figure 2 Incremental titrations.
