Taarup 7640 - 5.4 Main components of the wrapper

17
1
4
9
3
8
2
11
7
6
5
10
5.4 Main components of the wrapper
1 Main frame
2 Drawbar
3 Roller table
4 Loading arm
5 Support roller
6 Tower
7 Satellite with safety arm
8 Film prestretcher
9 Filmcutter
* Control unit model M
** Control unit model S
***Control panel model C
11 Hydraulic valve bank
Main components
