22
Operator´s manual round bale wrapper 7640
6.2 Connection to tractor or baler
6.2.1 Connecting to tractor
Connect drawbar to tractor’s drawbar/
hitch. Use the drawbar eye bushing when
connecting to tractor drawbar. Fit with
ring and circlip on the upper side in order
to avoid damage to bushing.
Connect the hydraulics. The return oil
must go directly to tank.
Connect the electrical cables.
Preparation for use
6.2.2 Connecting to baler
Connect drawbar to the baler hitch. Use
the drawbar eye bushing if necessary.
Connect the safety chain between the
baler and the wrapper.
Connect the wrapper hydraulics to the
tractors priority valve. The return oil must
go directly to tank.
Connect the electrical cables.
Check that the tractor can operate the
baler pick-up, as the wrapper hydraulics
run by constant oilflow.
Adjust the drawbar so the wrapper is
positionned as illustrated. Close the
ballvalve when it is positionned.
