43
Select key no. 3 in Process mode
Selects the zero set functions for the machine. If the key is pres-
sed in the Process Mode screen, an active icon will appear above
the key to indicate the current zero set selection function. There
are two zero set modes (repeated pressing on key for access to
next set mode):
a. Set the machine to work position.
b. Set the machine to transport position.
To activate the selected zero setting the “=/OK” switch must be
operated when the desired icon is in the screen (disappears after
2 seconds).
Select key no. 4 in Process mode:
Not in use
10.4.1.5 Joystick function key
Idle mode
Activates user functions
Process mode Auto or Manual
Selects if Joystick right / left shall operate loading arm or drawbar.
Chosen function is displayed.
Processmode PIA
Activates tool mode after two key actvations
Tool mode:
Select joystick function group for manual control (in Tool mode
only). Selected functions are shown as a graphic image on
screen.
10.4.1.6 Clear switch
Process Mode:
Clears (reset to 00) the error code in the screen.
Edit Mode:
Sets the edited value back to the minimum value allowed for that
parameter.
Operating model C
