GPIB INTERFACE (IEEE-488-1978) - Option 1
Programmable controls: All front panel controls except POWER switch; Output may be disabled through
a bus command
Subsets: SH1, AH1, T6, TE0, L4, LE0, SR1, RL1, PP2, DC1, DT1, C0
Data Output Format: Fixed output format consisting of 15 or 17 ASCII characters plus terminators
Data Input Format: ASCII characters lower or upper case. ASCII characters smaller than 20 HEX (32) are
ignored except CR (0D HEX)
Service Request: Selectable for illegal commands, illegal parameters and error
String Termination: Selectable CR, LF, EOI or combination of all.
Address Selection: Front panel programming. Address is stored in a non-volatile memory
ENVIRONMENTAL
Operating temperature: 0 deg C to 40 deg C ambient
Specified Accuracy: +25 deg C +/-5 deg C
Storage temperature: -40 deg C to +70 deg C
Humidity range: 80% R.H
GENERAL
Display: 4 digits 7 segment LEDs 14.2mm high with automatic decimal point, exponent and polarity
indicators
Power: 115/230 Vac +/- 10 %, 50 or 60 Hz, 50 VA max
Stored Settings: 30 complete sets of front panel control settings. The previous control settings and GPIB ad-
dress are stored in a non-volatile memory. Storage guaranteed for 24 month
Dimensions: 87 x 210 x 390 mm (H x W x L)
Weight: Approximately 5 Kg
Table 1-1. Model 8020 Specifications (continued)
General Information Model 8020
Page 1-6
