Tabor 8020 - Model 8020 Parts List - Final Amplifier Board Assembly

Table 8-1. Model 8020 Parts List - Main Board Assembly (continued)
REF DESCRIPTION PART #
R172 RES VAR 2K 3386F 0203-02020
R174 RES COMP 1K 0100-01020
R175 RES COMP 10K 0100-01030
R176 RES COMP 10K 0100-01030
R177 RES COMP 100K 0100-01040
R178 RES COMP 10K 0100-01030
U1 IC BFER 9668 (L204) 0500-11600
U2 IC P8279 0500-20700
U3 IC 74HC4049 0520-07300
U4 IC 74LS138 0510-02700
U5 IC P8031 0500-21410
U6 IC SN74HC4040 0520-07000
U7 IC 74LS373 0510-03650
U8 IC 27256 0500-21240
U9 IC MK48ZO2B-20 0500-11160
U10 IC 74HCT4040 PLL 0520-07200
U11 IC 74LS00 0510-00100
U12 IC 74LS74 0510-01100
U13 IC 74LS51 0510-00810
U14 IC P8291A 0500-21300
U15 IC BUFFER DS75160N 0500-21510
U16 IC BUFFER DS75161N 0500-21520
U17 IC REGULATOR MC7924CP 0500-52700
U18 IC REGULATOR MC7824CP 0500-52600
U19 IC REGULATOR MC7915CP 0500-52500
U20 IC REGULATOR LM317T 0500-53600
U21 IC OP AMP LM308A 0500-53400
REF DESCRIPTION PART #
U22 IC 74LS00 0510-00100
U23 IC 74F00 0500-11900
U25 IC LM308A 0500-53400
U26 IC LM308A 0500-53400
U27 IC LM308A 0500-53400
U28 IC LM308A 0500-53400
U29 IC CD4094B 0540-01100
U30 IC CD4094B 0540-01100
U31 IC CD4094B 0540-01100
U33 IC LM741C 0500-56310
U34 IC 12 BIT D/A AD7541AJN 0560-00800
U35 IC 10 BIT D/A AD7533JN 0560-00700
U36 IC LM741C 0500-56310
U37 IC LM741C 0500-56310
U38 IC CD4094B 0540-01100
U39 IC QUAD OP AMP LM324 0500-53210
U40 IC OP AMP TL081CP 0500-56700
U41 IC LM741C 0500-56310
U42 IC ANALOG SW DG211CJ 0500-90900
U43 IC ARRAY CA3102BE 0500-57700
U44 IC LM741C 0500-56310
U45 IC ARRAY CA3127E 0500-60000
U46 IC ARRAY CA3127E 0500-60000
U47 IC ARRAY CA3127E 0500-60000
U48 IC OP AMP CA3140E 0500-57200
U49 IC ANALOG SW DG211CJ 0500-90900
Table 8-2. Model 8020 Parts List - Final Amplifier Board Assembly
REF DESCRIPTION PART #
C1 CAP CER .1 -20%+80% 50V 1500-01040
C4 CAP CER .1 -20%+80% 50V 1500-01040
C5 CAP CER .1 -20%+80% 50V 1500-01040
C6 SELECTED
C7 SELECTED
C8 CAP CER .1 -20%+80% 50V 1500-01040
C10 CAP CER .1 -20%+80% 50V 1500-01040
C11 CAP CER .1 -20%+80% 50V 1500-01040
C12 CAP CER .1 -20%+80% 50V 1500-01040
C13 CAP CER .1 -20%+80% 50V 1500-01040
C14 CAP CER 15P 20% 50V 1500-01500
C16 CAP CER .1 -20%+80% 50V 1500-01040
C17 CAP CER .1 -20%+80% 50V 1500-01040
C18 CAP CER .1 -20%+80% 50V 1500-01040
C19 CAP CER .1 -20%+80% 50V 1500-01040
C20 CAP CER .1 -20%+80% 50V 1500-01040
C21 SELECTED
C22 CAP CER 27P 20% 63V 1500-02700
C23 SELECTED
C24 CAP CER .1 -20%+80% 50V 1500-01040
C25 CAP CER .1 -20%+80% 50V 1500-01040
C26 CAP CER .1 -20%+80% 50V 1500-01040
C27 CAP CER .1 -20%+80% 50V 1500-01040
C28 CAP CER 1n 20% 50V 1500-01020
C29 CAP CER 1n 20% 50V 1500-01020
C30 CAP CER 4.7P 20% 50V 1500-04R70
REF DESCRIPTION PART #
C31 CAP CER 1n 20% 50V 1500-01020
C32 CAP CER 1n 20% 50V 1500-01020
C33 CAP CER 100P 20% 50V 1500-01010
C34 CAP CER 1n 20% 50V 1500-01020
C36 CAP CER .1 -20%+80% 50V 1500-01040
C37 CAP CER 1n 20% 50V 1500-01020
C38 CAP CER 1n 20% 50V 1500-01020
C39 CAP CER 1n 20% 50V 1500-01020
C41 CAP CER 10P 20% 50V 1500-01000
C42 CAP CER .1 -20%+80% 50V 1500-01040
C43 CAP CER .1 -20%+80% 50V 1500-01040
C44 CAP CER 33P 20% 50V 1500-03300
C45 CAP CER .1 -20%+80% 50V 1500-01040
C46 CAP CER .1 -20%+80% 50V 1500-01040
C47 CAP CER .1 -20%+80% 50V 1500-01040
C48 CAP CER .1 -20%+80% 50V 1500-01040
C49 CAP CER .1 -20%+80% 50V 1500-01040
C50 CAP CER .1 -20%+80% 50V 1500-01040
C51 CAP CER 100P 20% 50V 1500-01010
C52 CAP CER .1 -20%+80% 50V 1500-01040
C53 CAP CER .1 -20%+80% 50V 1500-01040
C54 CAP CER .1 -20%+80% 50V 1500-01040
C55 CAP CER .1 -20%+80% 50V 1500-01040
C56 CAP CER .1 -20%+80% 50V 1500-01040
C57 CAP CER 43P 20% 50V 1500-04300
C58 CAP TANT 10 35V 1540-0106A
Parts List Model 8020
Page 8-4
