8.1 GENERAL
This section contains information for ordering replacement
parts. the replacement parts are available from Tabor Elec-
tronics. Mechanical parts are shown separately on Figure 8-
1.
8.2 ORDERING INFORMATION
When ordering replacement parts, always include the fol-
lowing information:
a) Instrument Model number.
b) Instrument Serial number.
c) Tabor part number.
d) Part description.
e) Circuit designation (where applicable).
8.3 PARTS DESCRIPTION
In the following Parts List Tables, unless otherwise noted,
resistors are 5% 1/4W, resistance is given in ohms, and ca-
pacitance is given in uF.
SECTION 8
PARTS LIST
REF DESCRIPTION PART #
C1 CAP CER .1 -20+80% 50V 1500-01040
C2 CAP CER .1 -20+80% 50V 1500-01040
C3 CAP CER .1 -20+80% 50V 1500-01040
C4 CAP CER .1 -20+80% 50V 1500-01040
C5 CAP CER .1 -20+80% 50V 1500-01040
C6 CAP CER .1 -20+80% 50V 1500-01040
C7 CAP CER .1 -20+80% 50V 1500-01040
C8 CAP CER .1 -20+80% 50V 1500-01040
C9 CAP CER .1 -20+80% 50V 1500-01040
C10 CAP CER .1 -20+80% 50V 1500-01040
C11 CAP CER .1 -20+80% 50V 1500-01040
C12 CAP CER .1 -20+80% 50V 1500-01040
C13 CAP CER .1 -20+80% 50V 1500-01040
C14 CAP ELEC 2200 25V 1533-02280
C15 CAP ELEC 2200 25V 1533-02280
C16 CAP ELEC 100 25V 1533-01070
C17 CAP ELEC 100 25V 1533-01070
C18 CAP ELEC 1000 50V 1535-01080
C19 CAP ELEC 1000 50V 1535-01080
C20 CAP ELEC 100 25V 1533-01070
C21 CAP ELEC 100 25V 1533-01070
C22 CAP ELEC 470 16V 1532-04770
C23 CAP ELEC 10000 16V 1532-01090
C24 CAP ELEC 220 16V 1532-02270
C25 CAP CER 33P 20% 50V 1500-03300
C26 CAP CER 1n 20% 50V 1500-01020
C27 CAP CER .1 -20+80% 50V 1500-01040
C28 CAP CER 56P 20% 50V 1500-05600
C29 CAP CER 47P 20% 50V 1500-04700
C30 CAP CER 47P 20% 50V 1500-04700
C31 CAP CER 1n 20% 50V 1500-01020
C32 CAP CER 1n 20% 50V 1500-01020
Table 8-1. Model 8020 Parts List - Main Board Assembly
REF DESCRIPTION PART #
C33 CAP CER 47P 20% 50V 1500-04700
C34 CAP CER 47P 20% 50V 1500-04700
C35 CAP TANT 10 35V 1540-0106A
C36 CAP TANT 10 35V 1540-0106A
C37 CAP MICA 220P 10% 500V 1510-02210
C38 CAP VAR 5-18P DV11PS18A 1550-01800
C40 CAP MICA 820P 10% 300V 1510-08210
C42 CAP POLY 4700P 2% 160V 1520-04720
C43 CAP POLY 4700P 2% 160V 1520-04720
C45 CAP POLY .1 1% 63V 1520-01040
C46 CAP POLY 1 1% 63V 1520-01050
C47 CAP CER .1 -20+80% 50V 1500-01040
C48 CAP CER .1 -20+80% 50V 1500-01040
C49 CAP CER .1 -20+80% 50V 1500-01040
C50 CAP CER .1 -20+80% 50V 1500-01040
C51 CAP CER .1 -20+80% 50V 1500-01040
C52 CAP TANT 10 35V 1540-0106A
C53 CAP CER .1 -20+80% 50V 1500-01040
C54 CAP TANT 10 35V 1540-0106A
C55 CAP CER 33P 20% 50V 1500-03300
C57 CAP CER 47P 20% 50V 1500-04700
C58 CAP CER 22P 20% 50V 1500-02200
C59 CAP CER 47P 20% 50V 1500-04700
C60 CAP VAR 7-40P 5MM 1550-02000
C61 CAP CER .1 -20+80% 50V 1500-01040
C62 CAP CER .1 -20+80% 50V 1500-01040
C63 CAP CER .1 -20+80% 50V 1500-01040
C64 CAP POLY 2.2 63V 5% 1522-02250
C65 CAP CER .1 -20+80% 50V 1500-01040
C66 CAP CER .1 -20+80% 50V 1500-01040
C67 CAP CER .1 -20+80% 50V 1500-01040
C68 CAP MICA SELECTED (12P TYP.)
Model 8020 Parts List
Page 8-1
