138 Appendix D TB9400 Cable Kits TB9400/TN9275 Installation and Operation
© Tait International Limited May 2023
Appendix D TB9400 Cable Kits
Cable kits exist to provide replacement cables for the TB9400 subracks.
This means customers do not have to order individual cables.
Cable Kits
T01-01150-0003 - TB9400 Kit Cable Single 50W Channel Upgrade
This kit is for adding a second reciter and 50W PA to a TB9400 subrack. It
contains the following cables:
2 X 150mm SMA RF Cable reciter to PA
1 X 150mm 8-way cable PA to subrack board
1 X 85mm 20-way cable reciter to subrack board
1 X 175mm Power cable from PMU to subrack board
Also included are a clamp and screw to secure the PA, and a cable clamp
to secure the PA power cable
T01-01150-0005 - TB9400 Kit Cable Single 100W Replacement Cable Set
This kit contains a set of replacement cables for the 100W TB9400 subrack.
It contains the following cables:
1 X 225mm SMA RF Cable reciter to PA
1 X 150mm SMA RF Cable reciter to PA
1 X 100mm 16-way cable PMU to subrack board
1 X 150mm 8-way cable PA to subrack board
1 X 90mm 20-way cable reciter to subrack board
1 X 130mm Power cable from PMU to subrack board
Also included are a clamp and screw to secure the PA, and a cable clamp
to secure the PA power cable
T01-01150-0007 TB9400 Single 50W Replacement Cable Set
This kit contains a set of replacement cables for a single 50W TB9400
subrack. It contains the following cables:
2 X 150mm SMA RF Cable reciter to PA
1 X 100mm 16-way cable PMU to subrack board
1 X 150mm 8-way cable PA to subrack board
1 X 90mm 20-way cable reciter to subrack board
