Tait TB9400 User Manual

TB9400/TN9275 Installation and Operation Installation 61
© Tait International Limited May 2023
TN9257 P25 Analog
Gateway Product
Code
The TN9257 P25 analog gateway product code is T01-01107-ABAA.
PA Product Codes
PMU Product
Codes
Product Code Description
T01-01121-X
XXX Frequency Band
B = 136 MHz to 174 MHz
J = 378MHz to 420MHz
K = 400MHz to 440MHz
L = 440MHz to 480MHz
M =470MHz to 520MHz
N = 762MHz to 870MHz
a
a. The actual frequency coverage in this band when used with a K band
TB9400 reciter is 762MHz to 776MHz and 850MHZ to 870MHz.
Tait Band Identifier
B1 band
HH band
H1 band
H2 band
H3 band
K4 band
T01-01121-XX
XX A = 50W
B = 100W
T01-01121-XXX
X A = default
T01-01121-XXXX
A = default
B = no internal Isolator
T01-01121-XXXX A = default
Product Code Description
TBAX
XXX-XXXX 3 = PMU
TBA3X
XX-XXXX 0 = default
TBA3XX
X-XXXX 0 = AC module not fitted
A = AC module fitted
TBA3XXX
-XXXX 0 = DC module not fitted
1 = 12V DC module fitted
2 = 24V DC module fitted
4 = 48V DC module fitted
TBA3XXX-XXXX 0 = standby power supply card not fitted
1 = 12VDC standby power supply card fitted
2 = 24VDC standby power supply card fitted
4 = 48VDC standby power supply card fitted
TBA3XXX-XXXX 0 = auxiliary power supply board not fitted
1 = 12VDC auxiliary power supply board fitted
2 = 24VDC auxiliary power supply board fitted
4 = 48VDC auxiliary power supply board fitted
TBA3XXX-XXXX 0 = default
TBA3XXX-XXXX
0 = default
