Tait TM8000 Series

72 TMAA10-04 Hands-Free Kit TM8000 Mobile Radio Accessories Manual
March 2004 © Tait Electronics Limited
Ref. IPN Description
Ref. IPN Description
9.5 PCB Information
9.5.1 TMAA10-04 Parts List (PCB IPN 220-01711-01)
C2 015-26330-08 Cap Cer 0805 330n 5% 10v X7r
C3 018-15100-00 Cap 0603 10n 50v X7r +-10%
C4 015-26330-08 Cap Cer 0805 330n 5% 10v X7r
C6 015-26100-08 Cap Cer 0805 100n 10% X7r 50v
C7 015-26100-08 Cap Cer 0805 100n 10% X7r 50v
Q1 000-10084-71 Xstr BC847BW NPN SOT323
Q2 000-10085-71 Xstr SMD BC857BW PNP SOT323
Q3 000-10084-71 Xstr BC847BW NPN SOT323
Q4 000-10084-71 Xstr BC847BW NPN SOT323
R1 038-14220-00 Res 0603 2k2 1/16w +-5%
R3 038-14390-10 Res 0603 3k9 1%
R4 038-15470-10 Res 0603 47k 1/16w+-1%
R6 038-15330-10 Res 0603 33k 1%
R13 038-15100-10 Res 0603 10k 1/16w +-1%
R16 038-15470-10 Res 0603 47k 1/16w+-1%
R17 038-15150-00 Res 0603 15k 1/16w +-5%
R18 038-15100-10 Res 0603 10k 1/16w +-1%
R19 038-15100-10 Res 0603 10k 1/16w +-1%
219-00305-00 cable
220-01711-01 Pcb HFree
236-00001-00 Sw Ptt W/Cbl & Strap
240-00020-55 Plg 15w Drng 105 Deg Pnl Mtg
240-06010-18 Conn 15w Hood/Cvr Drng MDJ15
252-00010-72 Mic Electret Unidir 2.5mm Plg
402-00006-00 F/Inst TMAA10-04 Kit HFree Eng
