2-19
CONTROLS
<TL8>
Initial
condition
LR common,
standard flow
Variable
range
Auxiliary 1st-1
100%=72L/min
(19.0 US gpm)
10 to 100%
Auxiliary 1st-2
75%=54L/min
(14.3 US gpm)
10 to 100%
Auxiliary 1st-3
50%=36L/min
(9.5 US gpm)
10 to 100%
Initial
condition
LR common,
high-flow
Variable
range
Auxiliary 1st-1
100%=128L/min
(33.8 US gpm)
10 to 100%
Auxiliary 1st-2
75%=96L/min
(25.4 US gpm)
10 to 100%
Auxiliary 1st-3
50%=64L/min
(16.9 US gpm)
10 to 100%
The table shows the 1-way flow rate when
there is no load.
The above rates vary depending on the
conditions. Use them as a rough indication.
d. Press the Aux. 1st flow rate select
switch to confirm. At this time, the
values on the R side starts flashing.
Perform the same operation as for the L
side. The section to be set changes
each time the Aux. 1st flow rate select
switch is pressed.
e. Press and hold the Aux. 1st flow rate
select switch for approximately three
seconds to end changing flow rate
operation.
INSTRUMENT CLUSTER
<TL12>
Initial
condition
LR common,
standard flow
Variable
range
Auxiliary 1st-1
100%=88L/min
(23.2 US gpm)
10 to 100%
Auxiliary 1st-2
75%=66L/min
(17.4 US gpm)
10 to 100%
Auxiliary 1st-3
50%=44L/min
(11.6 US gpm)
10 to 100%
Initial
condition
LR common,
high-flow
Variable
range
Auxiliary 1st-1
100%=153L/min
(40.4 US gpm)
10 to 100%
Auxiliary 1st-2
75%=115L/min
(30.4 US gpm)
10 to 100%
Auxiliary 1st-3
50%=92L/min
(24.3 US gpm)
10 to 100%
<TL10>
Initial
condition
LR common,
standard flow
Variable
range
Auxiliary 1st-1
100%=77L/min
(20.3 US gpm)
10 to 100%
Auxiliary 1st-2
75%=58L/min
(15.3 US gpm)
10 to 100%
Auxiliary 1st-3
50%=39L/min
(10.3 US gpm)
10 to 100%
Initial
condition
LR common,
high-flow
Variable
range
Auxiliary 1st-1
100%=142L/min
(37.5 US gpm)
10 to 100%
Auxiliary 1st-2
75%=107L/min
(28.3 US gpm)
10 to 100%
Auxiliary 1st-3
50%=85L/min
(22.5 US gpm)
10 to 100%
