1 Introduction
4 TW9
Symbol Description
Horn
Fuel
Fuel level
Blower
Heating/ventilation
Windshield washer and wiper
system
Parking brake
Direction indicator LT/RT
Working floodlights
High-beam indicator
Rotating beacon
V
R
Travel direction
FWD/REV
Travel speed
FAST
Travel speed
SLOW
Working hydraulics shut-off
Unlocked
Locked
Float position
Symbol Description
Hazard warning system
Operating mode indicator
Operating hours
Lashing points
Suspension points for loading
by crane
First-aid kit
Fire extinguisher
On machine:
Safety distance
Danger of crushing
Danger of injury
The relevant notes in the
operating instructions should
be observed
Grease gun
Lubricating point
Air conditioning
